Product Details:
Place of Origin: China
Brand Name: MagicBox
Certification: CE, RoHS
Model Number: BWDS-4000A/B/C
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: 60*30*25 cm/carton; 28kg
Delivery Time: 10-15days
Payment Terms: T/T, Western Union, Paypal, Alipay
Supply Ability: 10000pcs/month
Detailed Product Description
Theory: Vacuum Pump Structure: Diaphragm Pump
Usage: Water Power: Electric
Standard Or Nonstandard: Nonstandard Fuel: Electric Power, Solar, Battery
Pressure: High Pressure Application: Bottled Water, Ice Maker, Coffee Machine



MagicBox Bottled Water PLUS Dispensing System BWDS4000

MagicBox BWDS4000 Series Bottled Water PLUS Dispensing System 12V 115V 230V Optional 0

The Most Reliable and Efficient Bottled Water Dispensing System You Can Buy!

       The new and improved Bottled Water PLUS is part of Surflo's premium water dispensing product line. When a water bottle is connected to the system, fresh water is available for use with coffee/tea machines, water dispensers, refrigerators, ice makers, or any other application where portable potable water is needed. The Bottled Water PLUS system is also designed for convenience-the pump shuts off when the water source is depleted, and when water is restored, the pump will automatically restart. This eliminates the chance of any damage to the appliance running dry.


ADVANTAGES



  • Illuminated On/Off Switch Provides clear visibility in dark cabinets or hard to reach places
  • Long Life Motor Ensures years of reliable operation.
  • Surflo® Diaphragm Pump Provides dependable run dry capabilities, extending the life of the pump.
  • Quick Disconnect Ports Allows for easy wand replacement in seconds.
  • Quiet Operation Equipped with noise dampening rubber feet to minimize noise pollution.
  • Thermal Protection Prevents overheating, protecting the pump and control box from damage.
  • Over the past 12 years, Surflo® Bottled Water Systems have helped serve over two million cups of coffee per day in cafes and coffee shops worldwide.
  • Backed by the Surflo brand of electric diaphragm pump technology, a brand enjoying over 10 years of operational excellence.
  • Surflo®'s robust electric diaphragm pump design, proven with over seven million units in service.
  • Surflo® Bottled Water Systems protect the environment by eliminating the need for a water filter when dispensing water to your refrigerator, preventing over 300,000 filters from being disposed of each year.



SPECIFICATIONS



Flow Rate

1.10 (gpm)
4.1 (lpm)

Max. Pressure

40 (psi)
2.76 (bar)

Dimensions

6.86H x 13.72W x 21.60D (cms)
2.7H x 5.4W x 8.5D (inches)

Voltage

115 or 230 (VAC)

Amp Draw

0.5 Amps for 115 VAC, 0.3 Amps for 230 VAC

Cycles

50/60 for AC models (Hz)

Weight

2.04 (kg)
4.5  (lb)





MagicBox BWDS4000 Series Bottled Water PLUS Dispensing System 12V 115V 230V Optional 1





MagicBox BWDS4000 Series Bottled Water PLUS Dispensing System 12V 115V 230V Optional 2







MagicBox BWDS4000 Series Bottled Water PLUS Dispensing System 12V 115V 230V Optional 3Flojet Dual Inlet Bottled Water Dispensing System 12V 110~120V 220~240V Optional

Flojet Dual Inlet Bottled Water Dispensing System 12V 110~120V 220~240V Optional





CHEMICAL RESISTANCE



Chemical Resistance Code Max Temperature Resistance Code

A —— Excellent

B —— Good

C —— Ordinary

× —— Unacceptable

- —— Unusable

1 —— 20℃(68F)

2 —— 40℃(104F)

3 —— 60℃(140F)

4 —— 80℃(176F)

5 —— 100℃(212F)

6 —— 120℃(248F)

CHEMICAL MATERIAL
PP PTFE FKM NBR EPDM 95 Ceramic
Sulfuric Acid 0-10% A4 A6 A6 B2 A4 A5
10-75% A3 A6 A4 X A3 A5
75-100% B2 A4 A4 B2 A5
Nitric Acid 10% A3 A5 A5 X A2 A5
30% A2 A6 A6 X A2 A5
50% B2 A3 A1 X X A5
Hydrochloric Acid 0-25% A4 A6 A3 B1 C3 A5
25-40% A4 A6 A2 X C2 A5
Hydrofluoric Acid 10% B2 A6 A3 X A3
30% C2 A6 A4 B3
60% X A6 A4 C2
Acetic Acid 20% A2 A6 B1 B2 A2 A5
80% B1 A6 X A5
Sodium Hydroxide 20% A3 A6 B1 B2 A3
50% A3 A6 X B1 A4
Bromine Water C1 A3 A2 X A1
Ethyl Alcohol A2 A3 A3 X B3 A3
Acetone A2 A6 X B2 A3
Freon 12 X A6 A1 X B1 A4
Aluminum Chloride A4 A6 A5 B4 A4 A4
Ammonia Liquid A1 A6 C1 B4 B3 A3
Aqua Regia C2 A5 B2 C2 A4
Formaldehyde A4 A6 A4 X A4 A4
Gasoline X A6 B3 B3 X A4
Kerosene A1 A6 A1 B1 X A4
Methyl Alcohol A3 A6 B2 B4 A3 A5
Toluene C1 A4 B1 X A5
Trichloroethylene C1 A6 A1 X A4
Xylene X A6 B1 X A5
Nitric Acid Anhydrous C1 A3 A1 X A5
Oleum X A6 A4 X A5
Potassium Hydroxide A4 A6 B1 C2 A5
