Product Details:
Place of Origin: Guangdong, China
Brand Name: AQUAWING
Certification: CE, RoHS, FDA, NSF, ISO 9001: 2008
Model Number: KSP-1208-2420
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: 355*130*110mm
Delivery Time: samples 3-8 days, Big order 15-20days
Payment Terms: T/T (bank wire transfer), Western Union, Paypal, Alipay, Payoneer
Supply Ability: 5000pcs/month
Detailed Product Description
Theory: Vacuum Pump Structure: Diaphragm Pump
Usage: Water Power: Electric
Standard Or Nonstandard: Nonstandard Pressure: High Pressure
Application: Submersible Fuel: DC Power



AQUAWING KSP Solar submersible pump water pumps household batteries DC pumps irrigation pump drainagedeep well pumps 8-20L/min



AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 0





The solution to your remote water pumping needs. This pump is rugged.durable and builtto last. This pump delivers a steady 162GPH(600LPH) at its maximum depth of 230 feet (70m) when supplied with 24VDC. Its unique water-tight power connector stops water wicking and prevents potential condensation problems. Great for livestock watering.irrigation,pondaeration,remote homes and cabins



SPARE PARTS



Solar water pump

3 meters cable



FEATURES



1. For 4" wells or larger
2. Quick disconnect with "Watertight-Gland" Design Pat Pend
3. Corrosion-proof housing with stainless-steel fastener
4. Run dry without damage
5. State of the art solid diaphragm
6. Stainless Steel Fastener
7. Pump Design: Positive Displacement 3 Chamber Diaphragm Pump
8. Motor: Permanent Magnet Thermally Protected
9. Internal Bypass: 105-110 PSI Max. (7.2-7.5 BARS)
10. Outlet Port: 1/2" (12.7mm) Barbed Fitting
11. Inlet: 50 Mesh Stainless Steel Screen
12. Material: High Strength Engineered Plastic.





SPECIFICATIONS



MODEL NUMBER: KSP-1208
PUMP DESIGN: Positive Displacement 3 Chamber Diaphragm Pump
CAM: 3.0 Degree
MOTOR: Permanent Magnet, Thermally protected
VOLTAGE: 12 VDC Nominal (Reduced Volume @ 6VDC)
WATTS: 96W
AMPS: 8.0 MAX
FUSE: 8.5 AMP (Automotive) Not Included
INTERNAL BYPASS: 105-110 P.S.I. MAX (7.2-7.5 bars)
MAXIMUM LIFT: 230 ft (70 M)
SUBMERSION: 100ft (30 M) Maximum Below Waterline
OUTLET PORT: 1/2" (13 mm) Barbed Fitting
INLET: 50 Mesh Stainless Steel Screen
MATERIALS: High Strength Plastics Stainless Steel Hardware
APPLICATION: Potable water well pump
NET WEIGHT: 6 lbs (2.72 kg)





MODEL

VOLTS

VDC

OPEN FLOW GPM MAX. AMPS CONTROL MAX. SUBMERSION MAX. HEAD PORTS HOUSING MATERIAL VALVE MATERIAL DIAPHRAGM MATERIAL MOTOR FINISH MOTOR WIRING SUPPRESSION
KSP-1208 12 2.1 8 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE
KSP-2408 24 2.1 4.0 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE
KSP-1212 12 3.2 10 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE
KSP-2412 24 3.2 5 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE
KSP-1220 12 5.3 12 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE
KSP-2420 24 5.3 6 Bypass 100 Feet 230 Feet

1/2" Barb

with 1/2"NPT-M

Hose Kit

Fortron/Nylon EPDM Santoprene Submersible Case Cord Kit CE



DIMENSIONS DRAWINGS



AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 1

AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 2





TYPICAL APPLICATIONS



AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 3





EXPLODED VIEW



AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 4AQUAWING KSP Solar submersible water pump DC irrigation pump drainage deep well pump 8-20LPM 5





CHEMICAL RESISTANCE



Chemical Resistance Code Max Temperature Resistance Code

A —— Excellent

B —— Good

C —— Ordinary

× —— Unacceptable

- —— Unusable

1 —— 20℃(68F)

2 —— 40℃(104F)

3 —— 60℃(140F)

4 —— 80℃(176F)

5 —— 100℃(212F)

6 —— 120℃(248F)

CHEMICAL MATERIAL
PP PTFE FKM NBR EPDM 95 Ceramic
Sulfuric Acid 0-10% A4 A6 A6 B2 A4 A5
10-75% A3 A6 A4 X A3 A5
75-100% B2 A4 A4 B2 A5
Nitric Acid 10% A3 A5 A5 X A2 A5
30% A2 A6 A6 X A2 A5
50% B2 A3 A1 X X A5
Hydrochloric Acid 0-25% A4 A6 A3 B1 C3 A5
25-40% A4 A6 A2 X C2 A5
Hydrofluoric Acid 10% B2 A6 A3 X A3
30% C2 A6 A4 B3
60% X A6 A4 C2
Acetic Acid 20% A2 A6 B1 B2 A2 A5
80% B1 A6 X A5
Sodium Hydroxide 20% A3 A6 B1 B2 A3
50% A3 A6 X B1 A4
Bromine Water C1 A3 A2 X A1
Ethyl Alcohol A2 A3 A3 X B3 A3
Acetone A2 A6 X B2 A3
Freon 12 X A6 A1 X B1 A4
Aluminum Chloride A4 A6 A5 B4 A4 A4
Ammonia Liquid A1 A6 C1 B4 B3 A3
Aqua Regia C2 A5 B2 C2 A4
Formaldehyde A4 A6 A4 X A4 A4
Gasoline X A6 B3 B3 X A4
Kerosene A1 A6 A1 B1 X A4
Methyl Alcohol A3 A6 B2 B4 A3 A5
Toluene C1 A4 B1 X A5
Trichloroethylene C1 A6 A1 X A4
Xylene X A6 B1 X A5
Nitric Acid Anhydrous C1 A3 A1 X A5
Oleum X A6 A4 X A5
Potassium Hydroxide A4 A6 B1 C2 A5



USAGE SCOPE



Widely used in general industrial equipment, medical equipment, chemical equipment, agricultural (lawns and gardens), tourist vehicles, special vehicles, ships, beverage, vehicle cleaning, carpet cleaning, floor cleaning, water purification and water treatment equipment.
1. Production of agricultural use electric sprayer, pressure sprayer can also be hand modified electric sprayer (pressure sprayer in hand directly on the micro-pumps, adding a battery or hand lamp can be).
2. Solve vehicles, ships, yachts, boats, etc. in use diet, wash, shower, toilet, wash water.
3. Food and beverage processing and handling equipment, to achieve the transfer of liquid food, distribution, filling and so on.
4. Domestic water supply. For example, water-saving toilet, water-saving toilet, electric toilet, pressurized water system.
5. Solar energy industry.
6. Water purification industry. For example, purification equipment, water treatment equipment, drinking fountains, water machines. For towel disposal, drinking fountains, Coke machines, juice machines, dishwashers, disinfection machines, solar bonsai, car washing and other manufacturers supporting the glass.
7. Other liquid transfer needs, as well as measurement of spray equipment and systems. For example, garbage trucks, water truck, carpet cleaning equipment, floor cleaning equipment, cleaning equipment, vehicles, road construction equipment, medical equipment, chemical equipment, chemical equipment, disinfection equipment, cooling systems, pressurization systems.
