Size and weight: 100.5x84x64; 480g

Pump housing material: PA66 + 30% GF

Pump outlet outside diameter: 27mm

Pump inlet outer diameter: 27mm

Suitable medium: water, oil, and other acid solution

Maximum operating temperature: 60 ℃

Power: 2.5W-86.4W

Rated voltage: 24Vdc

Voltage: 5Vdc ~ 24Vdc

Maximum load current: 1900mA

Maximum flow: 41.7L / MIN

Maximum static head: 3.5m

Noise: <40dB

Waterproof grade: IP68 (submersible installed)

Life:> 30,000 hours

Power supply: DC power modules, solar panels

Widely used in general industrial equipment, medical equipment, chemical equipment, agricultural (lawns and gardens), tourist vehicles, special vehicles, ships, beverage, vehicle cleaning, carpet cleaning, floor cleaning, water purification and water treatment equipment.
1. Production of agricultural use electric sprayer, pressure sprayer can also be hand modified electric sprayer (pressure sprayer in hand directly on the micro-pumps, adding a battery or hand lamp can be).
2. Solve vehicles, ships, yachts, boats, etc. in use diet, wash, shower, toilet, wash water.
3. Food and beverage processing and handling equipment, to achieve the transfer of liquid food, distribution, filling and so on.
4. Domestic water supply. For example, water-saving toilet, water-saving toilet, electric toilet, pressurized water system.
5. Solar energy industry.
6. Water purification industry. For example, purification equipment, water treatment equipment, drinking fountains, water machines. For towel disposal, drinking fountains, Coke machines, juice machines, dishwashers, disinfection machines, solar bonsai, car washing and other manufacturers supporting the glass.
7. Other liquid transfer needs, as well as measurement of spray equipment and systems. For example, garbage trucks, water truck, carpet cleaning equipment, floor cleaning equipment, cleaning equipment, vehicles, road construction equipment, medical equipment, chemical equipment, chemical equipment, disinfection equipment, cooling systems, pressurization systems.
