Theory: | Magnetic Drive Gear Pump | Structure: | Gear Pump |
---|---|---|---|
Usage: | Pesticide Spraying | Power: | 180W |
Pressure: | -1~+20 Bar | Application: | Packing Machine |
Motor: | 2 Pole Motor | System Pressure: | -1~+20 Bar |
Ports: | G1/8" Or G1/4" | Working Style: | 24 Hours Continuous Worki |
Liquid: | Water,oil Chemical Liquid |
KGP-06K magnetic drive gear pump adopt the AC asynchronous motor as power; with the shaft ends of motor connected with the outer annual magnetic loops of REPM to drive the gear pump. This series are featured by constant speed, large torque and operating steadily for a long time. Meanwhile, under the power supply of 380V50(60)Hz,it can regulate the flow of pump if adopting the tri-phase AC variable frequency motor and mating converter.The whole KGP-06 series can be equipped with the type AC asynchronous motor.
Main applications:
Widely used in Science& teaching instrument; Transfer high temperature; Packing machine ;Medical treatment and medicine; Instrument testing; Fine chemistry; Pesticide spraying; Testing equipment.
Model | KGP | 06 | K | 04/09/13 | / | AC380 | - | 2 | |
Position | KGP-06K full range of gear pumps | 1 | 2 | ||||||
1 | Motor voltage | Tri-phase AC380 = Tri-phase AC.380V | |||||||
2 | Motor Types | 2 = 2 pole Motor 4 = 4-pole Motor |
Model | Rated pressure (bar) |
System pressure (bar) |
Flow rate (ml/min) 50/(60)HZ |
Power (W) |
Voltage (V) |
Ports |
KGP-06K04/AC380-2 |
5 |
-1~+20 |
50-800 /60-960 |
180 |
2 Poles Three-Phase/ 50(60)HZ AC 380V |
G1/8” or G1/4” |
KGP-06K09/AC380-2 |
5 |
100-1800/ 120-2160 |
||||
KGP-06K13/AC380-2 |
5 |
300-2400/ 360-2880 |
